EN
SKU
32-02-02.0481O
INVERTER SOLIS S6-EH3P10K-H-EU HIBRID
1 pcs.
- Stock in Olsztyn - 1 pcs.
- Stock in Gliwice -
Outlet
Products at special prices. Products in this OUTLET are sold "as is," meaning warranty for physical defects does not apply, and Corab is not liable for any damage that may arise in connection with the product, its condition, or its possible use in any way. By deciding to make a purchase, you also accept the risk of lack of warranty and the risk of being unable to connect the device to OSD. Corab's liability for warranty, guarantee, as well as non-performance or improper performance of obligations regarding product defects is excluded. If in doubt, please contact a consultant. Outlet category products can't be return.
Details
Modern SOLIS S6-EH3P10K-H-EU hybrid photovoltaic inverter for domestic applications.
Rated output power: 10kW.
Equipped with 4 MPPT - each serving one chain (4/1).
High supported current for MPPT: 16A.
High supported short-circuit current for MPPT: 24A.
Low start-up voltage: 160V.
High efficiency: 97.5%.
Equipped with emergency output and Backup function (for system with energy storage).
Energy storage support.
Rated output power: 10kW.
Equipped with 4 MPPT - each serving one chain (4/1).
High supported current for MPPT: 16A.
High supported short-circuit current for MPPT: 24A.
Low start-up voltage: 160V.
High efficiency: 97.5%.
Equipped with emergency output and Backup function (for system with energy storage).
Energy storage support.
More Information
| Weight | 30.20 kg |
|---|---|
| Producer | SOLIS INVERTERS |
| Purpose | Domestic |
| Efficiency | 97.50 % |
| Max DC Voltage | 1000.00 V |
| Start up voltage | 160.00 V |
| Height | 0.50 m |
| Warranty | 5.00 years |
| Falownik hybrydowy | Tak |
| Number of phases | Three-phase |
| MPPT number | 4.00 |
| Type | hybrid |
Download files
- Solis_certificate_EN_50549-1_EN_50549-10_S6-EH3P(3-10)K-H-EU(-OD)_S6-EH3P(5-10)K2-H(-OD)_EUR_V01.pdf
- Solis_certificate_EN_50549-1_PN-EN_50549-1_TypeA_B_S6-EH3P(3-10)K-H-EU(-PRO)(-OD)_S6-EH3P(5-10)K2-H(-OD)_Poland_V01.pdf
- Solis_certificate_EN300328_EN_301489_EN_55011_IEC_61000-6-1(-2)(-3)(-4)_EN_62109_EN_62479_EN_62920_S6-EH3P(3-10)K-H-EU(-OD)(-PRO)_S6-EH3P(5-10)K2-H(-OD)_S6-EH3P7K-H-LV_RED_V02.pdf
- Solis_certificate_IEC_61000-3-2(-3)_S6-EH3P(3-10)K-H-EU(-PRO)(-OD)_S6-EH3P(5-10)K2-H(-OD)_Flicker_harmonic_V01.pdf
- Solis_certificate_IEC_EN_62109-1(-2)_S6-EH3P(3-10)K-H-EU(-PRO)(-OD)_S6-EH3P(3-10)K2-H(-OD)_Safety_V01.pdf
- Solis_certificate_IEC_EN_62109-1(-2)_S6-EH3P(3-10)K-H-EU(-PRO)(-OD)_S6-EH3P(5-10)K2-H(-OD)_S6-EH3P7K-H-LV_Safety_V02(TUV_Mark).pdf
- Solis_Manual_S6-EH3P(3-10)K-H-EU_EUR_V1,8(20240619).pdf
- Solis_S6-EH3P(3-10)K-H-EU_Global_V2,8_2023_06_DATASHEET en.pdf
- Solis_S6-EH3P(3-10)K-H-EU_POL_V1,9_202406_ karta produktu pl.pdf
- Solis_certificate_EN 50549-1&PN-EN 50549-1 TypeA&B_S6-EH3P(3-10)K-H-EU_Poland_V01.pdf
- Solis_Warranty_Europe_2022_PL.pdf
- Deklaracja producenta - Kompatybilność baterii Corab.pdf
- Manufacturers Declaration - Corab Battery Compatibility.pdf
